www.ti.com SPRS717H –OCTOBER 2011–REVISED MAY 2015
Table 4-1. Pin Attributes (ZCE and ZCZ Packages) (continued)
BALL RESET BUFFER PULLUP
ZCE BALL ZCZ BALL TYPE BALL RESET RESET REL. ZCE POWER / HYS
PIN NAME [2] SIGNAL NAME [3] MODE [4] REL. STATE STRENGTH /DOWN TYPE I/O CELL [13]
NUMBER [1] NUMBER [1] [5] STATE [6] MODE [8] ZCZ POWER [9] [10]
[7] (mA) [11] [12]
U5 U3 LCD_DATA10
(5)
lcd_data10 0 I/O Z Z 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a14 1 O
ehrpwm1A 2 O
mcasp0_axr0 3 I/O
pr1_mii0_rxd1 5 I
uart3_ctsn 6 I
gpio2_16 7 I/O
V5 U4 LCD_DATA11
(5)
lcd_data11 0 I/O Z Z 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a15 1 O
ehrpwm1B 2 O
mcasp0_ahclkr 3 I/O
mcasp0_axr2 4 I/O
pr1_mii0_rxd0 5 I
uart3_rtsn 6 O
gpio2_17 7 I/O
V6 V2 LCD_DATA12
(5)
lcd_data12 0 I/O Z Z 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a16 1 O
eQEP1A_in 2 I
mcasp0_aclkr 3 I/O
mcasp0_axr2 4 I/O
pr1_mii0_rxlink 5 I
uart4_ctsn 6 I
gpio0_8 7 I/O
U6 V3 LCD_DATA13
(5)
lcd_data13 0 I/O Z Z 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a17 1 O
eQEP1B_in 2 I
mcasp0_fsr 3 I/O
mcasp0_axr3 4 I/O
pr1_mii0_rxer 5 I
uart4_rtsn 6 O
gpio0_9 7 I/O
