AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H –OCTOBER 2011–REVISED MAY 2015
www.ti.com
Table 4-1. Pin Attributes (ZCE and ZCZ Packages) (continued)
BALL RESET BUFFER PULLUP
ZCE BALL ZCZ BALL TYPE BALL RESET RESET REL. ZCE POWER / HYS
PIN NAME [2] SIGNAL NAME [3] MODE [4] REL. STATE STRENGTH /DOWN TYPE I/O CELL [13]
NUMBER [1] NUMBER [1] [5] STATE [6] MODE [8] ZCZ POWER [9] [10]
[7] (mA) [11] [12]
V3 T3 LCD_DATA6
(5)
lcd_data6 0 I/O Z Z 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a6 1 O
pr1_edio_data_in6 2 I
eQEP2_index 3 I/O
pr1_edio_data_out6 4 O
pr1_pru1_pru_r30_6 5 O
pr1_pru1_pru_r31_6 6 I
gpio2_12 7 I/O
U3 T4 LCD_DATA7
(5)
lcd_data7 0 I/O Z Z 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a7 1 O
pr1_edio_data_in7 2 I
eQEP2_strobe 3 I/O
pr1_edio_data_out7 4 O
pr1_pru1_pru_r30_7 5 O
pr1_pru1_pru_r31_7 6 I
gpio2_13 7 I/O
V4 U1 LCD_DATA8
(5)
lcd_data8 0 I/O Z Z 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a12 1 O
ehrpwm1_tripzone_input 2 I
mcasp0_aclkx 3 I/O
uart5_txd 4 O
pr1_mii0_rxd3 5 I
uart2_ctsn 6 I
gpio2_14 7 I/O
W4 U2 LCD_DATA9
(5)
lcd_data9 0 I/O Z Z 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a13 1 O
ehrpwm0_synco 2 O
mcasp0_fsx 3 I/O
uart5_rxd 4 I
pr1_mii0_rxd2 5 I
uart2_rtsn 6 O
gpio2_15 7 I/O
32 Terminal Configuration and Functions Copyright © 2011–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
