AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H –OCTOBER 2011–REVISED MAY 2015
www.ti.com
Table 4-1. Pin Attributes (ZCE and ZCZ Packages) (continued)
BALL RESET BUFFER PULLUP
ZCE BALL ZCZ BALL TYPE BALL RESET RESET REL. ZCE POWER / HYS
PIN NAME [2] SIGNAL NAME [3] MODE [4] REL. STATE STRENGTH /DOWN TYPE I/O CELL [13]
NUMBER [1] NUMBER [1] [5] STATE [6] MODE [8] ZCZ POWER [9] [10]
[7] (mA) [11] [12]
NA R14 GPMC_A4 gpmc_a4 0 O L L 7 NA / VDDSHV3 Yes 6 PU/PD LVCMOS
gmii2_txd1 1 O
rgmii2_td1 2 O
rmii2_txd1 3 O
gpmc_a20 4 O
pr1_mii1_txd0 5 O
eQEP1A_in 6 I
gpio1_20 7 I/O
NA V15 GPMC_A5 gpmc_a5 0 O L L 7 NA / VDDSHV3 Yes 6 PU/PD LVCMOS
gmii2_txd0 1 O
rgmii2_td0 2 O
rmii2_txd0 3 O
gpmc_a21 4 O
pr1_mii1_rxd3 5 I
eQEP1B_in 6 I
gpio1_21 7 I/O
NA U15 GPMC_A6 gpmc_a6 0 O L L 7 NA / VDDSHV3 Yes 6 PU/PD LVCMOS
gmii2_txclk 1 I
rgmii2_tclk 2 O
mmc2_dat4 3 I/O
gpmc_a22 4 O
pr1_mii1_rxd2 5 I
eQEP1_index 6 I/O
gpio1_22 7 I/O
NA T15 GPMC_A7 gpmc_a7 0 O L L 7 NA / VDDSHV3 Yes 6 PU/PD LVCMOS
gmii2_rxclk 1 I
rgmii2_rclk 2 I
mmc2_dat5 3 I/O
gpmc_a23 4 O
pr1_mii1_rxd1 5 I
eQEP1_strobe 6 I/O
gpio1_23 7 I/O
24 Terminal Configuration and Functions Copyright © 2011–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
