AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com
SPRS717H –OCTOBER 2011–REVISED MAY 2015
Table 4-1. Pin Attributes (ZCE and ZCZ Packages) (continued)
BALL RESET BUFFER PULLUP
ZCE BALL ZCZ BALL TYPE BALL RESET RESET REL. ZCE POWER / HYS
PIN NAME [2] SIGNAL NAME [3] MODE [4] REL. STATE STRENGTH /DOWN TYPE I/O CELL [13]
NUMBER [1] NUMBER [1] [5] STATE [6] MODE [8] ZCZ POWER [9] [10]
[7] (mA) [11] [12]
D14 B14 EMU1 EMU1 0 I/O H H 0 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpio3_8 7 I/O
C17 B18 EXTINTn nNMI 0 I Z H 0 VDDSHV6 / Yes NA PU/PD LVCMOS
VDDSHV6
B5 C5 EXT_WAKEUP EXT_WAKEUP 0 I L Z 0 VDDS_RTC / Yes NA NA LVCMOS
VDDS_RTC
NA R13 GPMC_A0 gpmc_a0 0 O L L 7 NA / VDDSHV3 Yes 6 PU/PD LVCMOS
gmii2_txen 1 O
rgmii2_tctl 2 O
rmii2_txen 3 O
gpmc_a16 4 O
pr1_mii_mt1_clk 5 I
ehrpwm1_tripzone_input 6 I
gpio1_16 7 I/O
NA V14 GPMC_A1 gpmc_a1 0 O L L 7 NA / VDDSHV3 Yes 6 PU/PD LVCMOS
gmii2_rxdv 1 I
rgmii2_rctl 2 I
mmc2_dat0 3 I/O
gpmc_a17 4 O
pr1_mii1_txd3 5 O
ehrpwm0_synco 6 O
gpio1_17 7 I/O
NA U14 GPMC_A2 gpmc_a2 0 O L L 7 NA / VDDSHV3 Yes 6 PU/PD LVCMOS
gmii2_txd3 1 O
rgmii2_td3 2 O
mmc2_dat1 3 I/O
gpmc_a18 4 O
pr1_mii1_txd2 5 O
ehrpwm1A 6 O
gpio1_18 7 I/O
NA T14 GPMC_A3 gpmc_a3 0 O L L 7 NA / VDDSHV3 Yes 6 PU/PD LVCMOS
gmii2_txd2 1 O
rgmii2_td2 2 O
mmc2_dat2 3 I/O
gpmc_a19 4 O
pr1_mii1_txd1 5 O
ehrpwm1B 6 O
gpio1_19 7 I/O
Copyright © 2011–2015, Texas Instruments Incorporated Terminal Configuration and Functions 23
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
