Left
Pin map section location
AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com
SPRS717H –OCTOBER 2011–REVISED MAY 2015
ZCZ Pin Map [Section Left - Top View]
A B C D E F
18 VSS EXTINTn ECAP0_IN_PWM0_OUT UART1_CTSn UART0_CTSn MMC0_DAT2
17 SPI0_SCLK SPI0_D0 I2C0_SDA UART1_RTSn UART0_RTSn MMC0_DAT3
16 SPI0_CS0 SPI0_D1 I2C0_SCL UART1_RXD UART0_TXD USB0_DRVVBUS
15 XDMA_EVENT_INTR0 PWRONRSTn SPI0_CS1 UART1_TXD UART0_RXD USB1_DRVVBUS
14 MCASP0_AHCLKX EMU1 EMU0 XDMA_EVENT_INTR1 VDDS VDDSHV6
13 MCASP0_ACLKX MCASP0_FSX MCASP0_FSR MCASP0_AXR1 VDDSHV6 VDD_MPU
12 TCK MCASP0_ACLKR MCASP0_AHCLKR MCASP0_AXR0 VDDSHV6 VDD_MPU
11 TDO TDI TMS CAP_VDD_SRAM_MPU VDDSHV6 VDD_MPU
10 WARMRSTn TRSTn CAP_VBB_MPU VDDS_SRAM_MPU_BB VDDSHV6 VDD_MPU
9 VREFN VREFP AIN7 CAP_VDD_SRAM_CORE VDDS_SRAM_CORE_BG VDDS
8 AIN6 AIN5 AIN4 VDDA_ADC VSSA_ADC VSS
7 AIN3 AIN2 AIN1 VDDS_RTC VDDS_PLL_DDR VDD_CORE
6 RTC_XTALIN AIN0 PMIC_POWER_EN CAP_VDD_RTC VDDS VDD_CORE
5 VSS_RTC RTC_PWRONRSTn EXT_WAKEUP DDR_A6 VDDS_DDR VDDS_DDR
4 RTC_XTALOUT RTC_KALDO_ENn DDR_BA0 DDR_A8 DDR_A2 DDR_A10
3 RESERVED DDR_BA2 DDR_A3 DDR_A15 DDR_A12 DDR_A0
2 VDD_MPU_MON DDR_WEn DDR_A4 DDR_CK DDR_A7 DDR_A11
1 VSS DDR_A5 DDR_A9 DDR_CKn DDR_BA1 DDR_CASn
Copyright © 2011–2015, Texas Instruments Incorporated Terminal Configuration and Functions 15
