Table 4-1. Pin Attributes (ZCE and ZCZ Packages) (continued)
BALL RESET BUFFER PULLUP
ZCE BALL ZCZ BALL TYPE BALL RESET RESET REL. ZCE POWER / HYS
PIN NAME [2] SIGNAL NAME [3] MODE [4] REL. STATE STRENGTH /DOWN TYPE I/O CELL [13]
NUMBER [1] NUMBER [1] [5] STATE [6] MODE [8] ZCZ POWER [9] [10]
[7] (mA) [11] [12]
E19 E15 UART0_RXD uart0_rxd 0 I Z H 7 VDDSHV6 / Yes 4 PU/PD LVCMOS
VDDSHV6
spi1_cs0 1 I/O
dcan0_tx 2 O
I2C2_SDA 3 I/OD
eCAP2_in_PWM2_out 4 I/O
pr1_pru1_pru_r30_14 5 O
pr1_pru1_pru_r31_14 6 I
gpio1_10 7 I/O
F18 E17 UART0_RTSn uart0_rtsn 0 O Z H 7 VDDSHV6 / Yes 4 PU/PD LVCMOS
VDDSHV6
uart4_txd 1 O
dcan1_rx 2 I
I2C1_SCL 3 I/OD
spi1_d1 4 I/O
spi1_cs0 5 I/O
pr1_edc_sync1_out 6 O
gpio1_9 7 I/O
C19 D15 UART1_TXD uart1_txd 0 O Z H 7 VDDSHV6 / Yes 4 PU/PD LVCMOS
VDDSHV6
mmc2_sdwp 1 I
dcan1_rx 2 I
I2C1_SCL 3 I/OD
pr1_uart0_txd 5 O
pr1_pru0_pru_r31_16 6 I
gpio0_15 7 I/O
D18 D16 UART1_RXD uart1_rxd 0 I Z H 7 VDDSHV6 / Yes 4 PU/PD LVCMOS
VDDSHV6
mmc1_sdwp 1 I
dcan1_tx 2 O
I2C1_SDA 3 I/OD
pr1_uart0_rxd 5 I
pr1_pru1_pru_r31_16 6 I
gpio0_14 7 I/O
D19 D17 UART1_RTSn uart1_rtsn 0 O Z H 7 VDDSHV6 / Yes 4 PU/PD LVCMOS
VDDSHV6
timer5 1 I/O
dcan0_rx 2 I
I2C2_SCL 3 I/OD
spi1_cs1 4 I/O
pr1_uart0_rts_n 5 O
pr1_edc_latch1_in 6 I
gpio0_13 7 I/O
