AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H –OCTOBER 2011–REVISED MAY 2015
www.ti.com
Table 4-1. Pin Attributes (ZCE and ZCZ Packages) (continued)
BALL RESET BUFFER PULLUP
ZCE BALL ZCZ BALL TYPE BALL RESET RESET REL. ZCE POWER / HYS
PIN NAME [2] SIGNAL NAME [3] MODE [4] REL. STATE STRENGTH /DOWN TYPE I/O CELL [13]
NUMBER [1] NUMBER [1] [5] STATE [6] MODE [8] ZCZ POWER [9] [10]
[7] (mA) [11] [12]
E17 D18 UART1_CTSn uart1_ctsn 0 I Z H 7 VDDSHV6 / Yes 4 PU/PD LVCMOS
VDDSHV6
timer6 1 I/O
dcan0_tx 2 O
I2C2_SDA 3 I/OD
spi1_cs0 4 I/O
pr1_uart0_cts_n 5 I
pr1_edc_latch0_in 6 I
gpio0_12 7 I/O
T18 M15 USB0_CE USB0_CE 0 A Z Z 0 VDDA*_USB0 / NA NA NA Analog
VDDA*_USB0
(26)
T19 P15 USB0_VBUS USB0_VBUS 0 A Z Z 0 VDDA*_USB0 / NA NA NA Analog
VDDA*_USB0
(26)
U18 N18 USB0_DM USB0_DM 0 A Z Z 0
(13)
VDDA*_USB0 / Yes 8
(16)
NA Analog
VDDA*_USB0
(16)
(26)
G16 F16 USB0_DRVVBUS USB0_DRVVBUS 0 O L 0(PD) 0 VDDSHV6 / Yes 4 PU/PD LVCMOS
VDDSHV6
gpio0_18 7 I/O
V19 P16 USB0_ID USB0_ID 0 A Z Z 0 VDDA*_USB0 / NA NA NA Analog
VDDA*_USB0
(26)
U19 N17 USB0_DP USB0_DP 0 A Z Z 0
(13)
VDDA*_USB0 / Yes 8
(16)
NA Analog
VDDA*_USB0
(16)
(26)
NA P18 USB1_CE USB1_CE 0 A Z Z 0 NA / NA NA NA Analog
VDDA*_USB1
(27)
NA P17 USB1_ID USB1_ID 0 A Z Z 0 NA / NA NA NA Analog
VDDA*_USB1
(27)
NA T18 USB1_VBUS USB1_VBUS 0 A Z Z 0 NA / NA NA NA Analog
VDDA*_USB1
(27)
NA R17 USB1_DP USB1_DP 0 A Z Z 0
(14)
NA / Yes 8
(17)
NA Analog
VDDA*_USB1
(17)
(27)
NA F15 USB1_DRVVBUS USB1_DRVVBUS 0 O L 0(PD) 0 NA / VDDSHV6 Yes 4 PU/PD LVCMOS
gpio3_13 7 I/O
NA R18 USB1_DM USB1_DM 0 A Z Z 0
(14)
NA / Yes 8
(17)
NA Analog
VDDA*_USB1
(17)
(27)
R17 N16 VDDA1P8V_USB0 VDDA1P8V_USB0 NA PWR
NA R16 VDDA1P8V_USB1 VDDA1P8V_USB1 NA PWR
R18 N15 VDDA3P3V_USB0 VDDA3P3V_USB0 NA PWR
NA R15 VDDA3P3V_USB1 VDDA3P3V_USB1 NA PWR
