Middle
Pin map section location
AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H –OCTOBER 2011–REVISED MAY 2015
www.ti.com
ZCZ Pin Map [Section Middle - Top View]
G H J K L M
18 MMC0_CMD RMII1_REF_CLK MII1_TXD3 MII1_TX_CLK MII1_RX_CLK MDC
17 MMC0_CLK MII1_CRS MII1_RX_DV MII1_TXD0 MII1_RXD3 MDIO
16 MMC0_DAT0 MII1_COL MII1_TX_EN MII1_TXD1 MII1_RXD2 MII1_RXD0
15 MMC0_DAT1 VDDS_PLL_MPU MII1_RX_ER MII1_TXD2 MII1_RXD1 USB0_CE
14 VDDSHV6 VDDSHV4 VDDSHV4 VDDSHV5 VDDSHV5 VSSA_USB
13 VDD_MPU VDD_MPU VDD_MPU VDDS VSS VDD_CORE
12 VSS VSS VDD_CORE VDD_CORE VSS VSS
11 VSS VDD_CORE VSS VSS VSS VDD_CORE
10 VDD_CORE VSS VSS VSS VSS VSS
9 VSS VSS VSS VSS VDD_CORE VSS
8 VSS VSS VSS VDD_CORE VDD_CORE VSS
7 VDD_CORE VSS VSS VSS VDD_CORE VSS
6 VDD_CORE VSS VSS VDD_CORE VDD_CORE VSS
5 VDDS_DDR VDDS_DDR VDDS_DDR VDDS_DDR VDDS_DDR VPP
4 DDR_RASn DDR_A14 DDR_VREF DDR_D12 DDR_D14 DDR_D1
3 DDR_CKE DDR_A13 DDR_VTP DDR_D11 DDR_D13 DDR_D0
2 DDR_RESETn DDR_CSn0 DDR_DQM1 DDR_D10 DDR_DQSn1 DDR_DQM0
1 DDR_ODT DDR_A1 DDR_D8 DDR_D9 DDR_DQS1 DDR_D15
16 Terminal Configuration and Functions Copyright © 2011–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
