AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com
SPRS717H –OCTOBER 2011–REVISED MAY 2015
Table 4-1. Pin Attributes (ZCE and ZCZ Packages) (continued)
BALL RESET BUFFER PULLUP
ZCE BALL ZCZ BALL TYPE BALL RESET RESET REL. ZCE POWER / HYS
PIN NAME [2] SIGNAL NAME [3] MODE [4] REL. STATE STRENGTH /DOWN TYPE I/O CELL [13]
NUMBER [1] NUMBER [1] [5] STATE [6] MODE [8] ZCZ POWER [9] [10]
[7] (mA) [11] [12]
J18 H17 MII1_CRS gmii1_crs 0 I L L 7 VDDSHV5 / Yes 6 PU/PD LVCMOS
VDDSHV5
rmii1_crs_dv 1 I
spi1_d0 2 I/O
I2C1_SDA 3 I/OD
mcasp1_aclkx 4 I/O
uart5_ctsn 5 I
uart2_rxd 6 I
gpio3_1 7 I/O
P18 M16 MII1_RXD0 gmii1_rxd0 0 I L L 7 VDDSHV5 / Yes 6 PU/PD LVCMOS
VDDSHV5
rmii1_rxd0 1 I
rgmii1_rd0 2 I
mcasp1_ahclkx 3 I/O
mcasp1_ahclkr 4 I/O
mcasp1_aclkr 5 I/O
mcasp0_axr3 6 I/O
gpio2_21 7 I/O
P19 L15 MII1_RXD1 gmii1_rxd1 0 I L L 7 VDDSHV5 / Yes 6 PU/PD LVCMOS
VDDSHV5
rmii1_rxd1 1 I
rgmii1_rd1 2 I
mcasp1_axr3 3 I/O
mcasp1_fsr 4 I/O
eQEP0_strobe 5 I/O
mmc2_clk 6 I/O
gpio2_20 7 I/O
N16 L16 MII1_RXD2 gmii1_rxd2 0 I L L 7 VDDSHV5 / Yes 6 PU/PD LVCMOS
VDDSHV5
uart3_txd 1 O
rgmii1_rd2 2 I
mmc0_dat4 3 I/O
mmc1_dat3 4 I/O
uart1_rin 5 I
mcasp0_axr1 6 I/O
gpio2_19 7 I/O
Copyright © 2011–2015, Texas Instruments Incorporated Terminal Configuration and Functions 39
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
