AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H –OCTOBER 2011–REVISED MAY 2015
www.ti.com
Table 4-1. Pin Attributes (ZCE and ZCZ Packages) (continued)
BALL RESET BUFFER PULLUP
ZCE BALL ZCZ BALL TYPE BALL RESET RESET REL. ZCE POWER / HYS
PIN NAME [2] SIGNAL NAME [3] MODE [4] REL. STATE STRENGTH /DOWN TYPE I/O CELL [13]
NUMBER [1] NUMBER [1] [5] STATE [6] MODE [8] ZCZ POWER [9] [10]
[7] (mA) [11] [12]
N17 L17 MII1_RXD3 gmii1_rxd3 0 I L L 7 VDDSHV5 / Yes 6 PU/PD LVCMOS
VDDSHV5
uart3_rxd 1 I
rgmii1_rd3 2 I
mmc0_dat5 3 I/O
mmc1_dat2 4 I/O
uart1_dtrn 5 O
mcasp0_axr0 6 I/O
gpio2_18 7 I/O
L18 K17 MII1_TXD0 gmii1_txd0 0 O L L 7 VDDSHV5 / Yes 6 PU/PD LVCMOS
VDDSHV5
rmii1_txd0 1 O
rgmii1_td0 2 O
mcasp1_axr2 3 I/O
mcasp1_aclkr 4 I/O
eQEP0B_in 5 I
mmc1_clk 6 I/O
gpio0_28 7 I/O
M18 K16 MII1_TXD1 gmii1_txd1 0 O L L 7 VDDSHV5 / Yes 6 PU/PD LVCMOS
VDDSHV5
rmii1_txd1 1 O
rgmii1_td1 2 O
mcasp1_fsr 3 I/O
mcasp1_axr1 4 I/O
eQEP0A_in 5 I
mmc1_cmd 6 I/O
gpio0_21 7 I/O
N18 K15 MII1_TXD2 gmii1_txd2 0 O L L 7 VDDSHV5 / Yes 6 PU/PD LVCMOS
VDDSHV5
dcan0_rx 1 I
rgmii1_td2 2 O
uart4_txd 3 O
mcasp1_axr0 4 I/O
mmc2_dat2 5 I/O
mcasp0_ahclkx 6 I/O
gpio0_17 7 I/O
40 Terminal Configuration and Functions Copyright © 2011–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
