AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com
SPRS717H –OCTOBER 2011–REVISED MAY 2015
Table 4-1. Pin Attributes (ZCE and ZCZ Packages) (continued)
BALL RESET BUFFER PULLUP
ZCE BALL ZCZ BALL TYPE BALL RESET RESET REL. ZCE POWER / HYS
PIN NAME [2] SIGNAL NAME [3] MODE [4] REL. STATE STRENGTH /DOWN TYPE I/O CELL [13]
NUMBER [1] NUMBER [1] [5] STATE [6] MODE [8] ZCZ POWER [9] [10]
[7] (mA) [11] [12]
M17 J18 MII1_TXD3 gmii1_txd3 0 O L L 7 VDDSHV5 / Yes 6 PU/PD LVCMOS
VDDSHV5
dcan0_tx 1 O
rgmii1_td3 2 O
uart4_rxd 3 I
mcasp1_fsx 4 I/O
mmc2_dat1 5 I/O
mcasp0_fsr 6 I/O
gpio0_16 7 I/O
G17 G18 MMC0_CMD mmc0_cmd 0 I/O H H 7 VDDSHV4 / Yes 6 PU/PD LVCMOS
VDDSHV4
gpmc_a25 1 O
uart3_rtsn 2 O
uart2_txd 3 O
dcan1_rx 4 I
pr1_pru0_pru_r30_13 5 O
pr1_pru0_pru_r31_13 6 I
gpio2_31 7 I/O
G19 G17 MMC0_CLK mmc0_clk 0 I/O H H 7 VDDSHV4 / Yes 6 PU/PD LVCMOS
VDDSHV4
gpmc_a24 1 O
uart3_ctsn 2 I
uart2_rxd 3 I
dcan1_tx 4 O
pr1_pru0_pru_r30_12 5 O
pr1_pru0_pru_r31_12 6 I
gpio2_30 7 I/O
G18 G16 MMC0_DAT0 mmc0_dat0 0 I/O H H 7 VDDSHV4 / Yes 6 PU/PD LVCMOS
VDDSHV4
gpmc_a23 1 O
uart5_rtsn 2 O
uart3_txd 3 O
uart1_rin 4 I
pr1_pru0_pru_r30_11 5 O
pr1_pru0_pru_r31_11 6 I
gpio2_29 7 I/O
Copyright © 2011–2015, Texas Instruments Incorporated Terminal Configuration and Functions 41
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
