Texas Instruments AM335x Sitara User Manual

AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com SPRS717H –OCTOBER 2011–REVISED MAY 2015
Table 4-1. Pin Attributes (ZCE and ZCZ Packages) (continued)
BALL RESET BUFFER PULLUP
ZCE BALL ZCZ BALL TYPE BALL RESET RESET REL. ZCE POWER / HYS
PIN NAME [2] SIGNAL NAME [3] MODE [4] REL. STATE STRENGTH /DOWN TYPE I/O CELL [13]
NUMBER [1] NUMBER [1] [5] STATE [6] MODE [8] ZCZ POWER [9] [10]
[7] (mA) [11] [12]
R19 M18 MDC mdio_clk 0 O H H 7 VDDSHV5 / Yes 6 PU/PD LVCMOS
VDDSHV5
timer5 1 I/O
uart5_txd 2 O
uart3_rtsn 3 O
mmc0_sdwp 4 I
mmc1_clk 5 I/O
mmc2_clk 6 I/O
gpio0_1 7 I/O
P17 M17 MDIO mdio_data 0 I/O H H 7 VDDSHV5 / Yes 6 PU/PD LVCMOS
VDDSHV5
timer6 1 I/O
uart5_rxd 2 I
uart3_ctsn 3 I
mmc0_sdcd 4 I
mmc1_cmd 5 I/O
mmc2_cmd 6 I/O
gpio0_0 7 I/O
L19 J17 MII1_RX_DV gmii1_rxdv 0 I L L 7 VDDSHV5 / Yes 6 PU/PD LVCMOS
VDDSHV5
lcd_memory_clk 1 O
rgmii1_rctl 2 I
uart5_txd 3 O
mcasp1_aclkx 4 I/O
mmc2_dat0 5 I/O
mcasp0_aclkr 6 I/O
gpio3_4 7 I/O
K17 J16 MII1_TX_EN gmii1_txen 0 O L L 7 VDDSHV5 / Yes 6 PU/PD LVCMOS
VDDSHV5
rmii1_txen 1 O
rgmii1_tctl 2 O
timer4 3 I/O
mcasp1_axr0 4 I/O
eQEP0_index 5 I/O
mmc2_cmd 6 I/O
gpio3_3 7 I/O
Copyright © 2011–2015, Texas Instruments Incorporated Terminal Configuration and Functions 37
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
