AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H –OCTOBER 2011–REVISED MAY 2015
www.ti.com
Table 4-1. Pin Attributes (ZCE and ZCZ Packages) (continued)
BALL RESET BUFFER PULLUP
ZCE BALL ZCZ BALL TYPE BALL RESET RESET REL. ZCE POWER / HYS
PIN NAME [2] SIGNAL NAME [3] MODE [4] REL. STATE STRENGTH /DOWN TYPE I/O CELL [13]
NUMBER [1] NUMBER [1] [5] STATE [6] MODE [8] ZCZ POWER [9] [10]
[7] (mA) [11] [12]
B17 B16 SPI0_D1 spi0_d1 0 I/O Z H 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
mmc1_sdwp 1 I
I2C1_SDA 2 I/OD
ehrpwm0_tripzone_input 3 I
pr1_uart0_rxd 4 I
pr1_edio_data_in0 5 I
pr1_edio_data_out0 6 O
gpio0_4 7 I/O
B14 A12 TCK TCK 0 I H H 0 VDDSHV6 / Yes NA PU/PD LVCMOS
VDDSHV6
B13 B11 TDI TDI 0 I H H 0 VDDSHV6 / Yes NA PU/PD LVCMOS
VDDSHV6
A14 A11 TDO TDO 0 O H H 0 VDDSHV6 / NA 4 PU/PD LVCMOS
VDDSHV6
C14 C11 TMS TMS 0 I H H 0 VDDSHV6 / Yes NA PU/PD LVCMOS
VDDSHV6
A13 B10 TRSTn nTRST 0 I L L 0 VDDSHV6 / Yes NA PU/PD LVCMOS
VDDSHV6
F17 E16 UART0_TXD uart0_txd 0 O Z H 7 VDDSHV6 / Yes 4 PU/PD LVCMOS
VDDSHV6
spi1_cs1 1 I/O
dcan0_rx 2 I
I2C2_SCL 3 I/OD
eCAP1_in_PWM1_out 4 I/O
pr1_pru1_pru_r30_15 5 O
pr1_pru1_pru_r31_15 6 I
gpio1_11 7 I/O
F19 E18 UART0_CTSn uart0_ctsn 0 I Z H 7 VDDSHV6 / Yes 4 PU/PD LVCMOS
VDDSHV6
uart4_rxd 1 I
dcan1_tx 2 O
I2C1_SDA 3 I/OD
spi1_d0 4 I/O
timer7 5 I/O
pr1_edc_sync0_out 6 O
gpio1_8 7 I/O
44 Terminal Configuration and Functions Copyright © 2011–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
