AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H –OCTOBER 2011–REVISED MAY 2015
www.ti.com
Table 4-1. Pin Attributes (ZCE and ZCZ Packages) (continued)
BALL RESET BUFFER PULLUP
ZCE BALL ZCZ BALL TYPE BALL RESET RESET REL. ZCE POWER / HYS
PIN NAME [2] SIGNAL NAME [3] MODE [4] REL. STATE STRENGTH /DOWN TYPE I/O CELL [13]
NUMBER [1] NUMBER [1] [5] STATE [6] MODE [8] ZCZ POWER [9] [10]
[7] (mA) [11] [12]
W18 U17 GPMC_WPn gpmc_wpn 0 O H H 7 VDDSHV1 / Yes 6 PU/PD LVCMOS
VDDSHV3
gmii2_rxerr 1 I
gpmc_csn5 2 O
rmii2_rxerr 3 I
mmc2_sdcd 4 I
pr1_mii1_txen 5 O
uart4_txd 6 O
gpio0_31 7 I/O
C18 C17 I2C0_SDA I2C0_SDA 0 I/OD Z H 7 VDDSHV6 / Yes 4 PU/PD LVCMOS
VDDSHV6
timer4 1 I/O
uart2_ctsn 2 I
eCAP2_in_PWM2_out 3 I/O
gpio3_5 7 I/O
B19 C16 I2C0_SCL I2C0_SCL 0 I/OD Z H 7 VDDSHV6 / Yes 4 PU/PD LVCMOS
VDDSHV6
timer7 1 I/O
uart2_rtsn 2 O
eCAP1_in_PWM1_out 3 I/O
gpio3_6 7 I/O
W7 R6 LCD_AC_BIAS_EN lcd_ac_bias_en 0 O Z L 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a11 1 O
pr1_mii1_crs 2 I
pr1_edio_data_in5 3 I
pr1_edio_data_out5 4 O
pr1_pru1_pru_r30_11 5 O
pr1_pru1_pru_r31_11 6 I
gpio2_25 7 I/O
U1 R1 LCD_DATA0
(5)
lcd_data0 0 I/O Z Z 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a0 1 O
pr1_mii_mt0_clk 2 I
ehrpwm2A 3 O
pr1_pru1_pru_r30_0 5 O
pr1_pru1_pru_r31_0 6 I
gpio2_6 7 I/O
30 Terminal Configuration and Functions Copyright © 2011–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
