BP-ADS7128 BoosterPack™ Plug-In Module
5 Bill of Materials, Printed Circuit Board Layout, and Schematics
This section contains the BP-ADS7128 bill of materials (BOM), printed circuit board (PCB) layout, and schematics.
5.1 Bill of Materials
Table 2 lists the bill of materials (BOM) for the ADS7128EVM.
Table 2. Bill of Materials
Designator Quantity Description Manufacturer Part Number Manufacturer
C1, C3 2 CAP, CERM, 1 uF, 25 V, +/- 10%, X7R, 0603 C0603C105K3RACTU Kemet
C4, C5, C9 3 CAP, CERM, 1 uF, 6.3 V, +/- 20%, X7R, 0402 GRM155R70J105MA12D MuRata
C6, C7, C8, C10, C11, C13,
C15
7 CAP, CERM, 160 pF, 50 V, +/- 5%, C0G/NP0, 0402 GRM1555C1H161JA01D MuRata
C12, C14 2 CAP, CERM, 0.1 µF, 25 V,+/- 10%, X5R, 0603 CL10A104KA8NNNC Samsung Electro-Mechanics
D2 1 LED, Red, SMD LTST-C150CKT Lite-On
J1, J3 2 Receptacle, 2.54mm, 10x2, Tin, TH SSQ-110-03-T-D Samtec
J4 1 Header, 100mil, 2x1, Tin, TH PEC02SAAN Sullins Connector Solutions
J5 1 Header, 100mil, 6x2, Tin, TH PEC06DAAN Sullins Connector Solutions
R2 1 RES, 1.69 M, 1%, 0.063 W, AEC-Q200 Grade 0, 0402 CRCW04021M69FKED Vishay-Dale
R3, R26 2 RES, 1.00 M, 1%, 0.1 W, 0402 ERJ-2RKF1004X Panasonic
R4 1 RES, 0, 5%, 0.063 W, 0402 RC0402JR-070RL Yageo America
R5, R6, R7 3 RES, 1.00 k, 1%, 0.063 W, 0402 MCR01MZPF1001 Rohm
R8, R9, R12, R14, R15,
R18, R20, R23
8 RES, 10.0 k, 1%, 0.063 W, 0402 RC0402FR-0710KL Yageo America
R17, R25 2 RES, 0, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 RMCF0603ZT0R00 Stackpole Electronics Inc
R19 1 RES, 2.20 k, 1%, 0.1 W, 0603 RC0603FR-072K2L Yageo
R24 1 RES, 169, 1%, 0.063 W, AEC-Q200 Grade 0, 0402 CRCW0402169RFKED Vishay-Dale
TP6, TP7 2 Test Point, Multipurpose, Black, TH 5011 Keystone
U1 1 Single Output LDO, 150 mA, Adjustable 1.22 to 5.25 V Output, 2.2 to 5.5 V
Input, with 500 nA Quiescent Current, 5-pin SOT (DDC), -40 to 125 degC,
Green (RoHS & no Sb/Br)
TPS78001DDCR Texas Instruments
U2 1 Small, 8-Channel, 12-bit ADC with I2C Interface, GPIOs & CRC,
RTE0016C_WF (WQFN-16)
ADS7128RTE Texas Instruments
U3 1 I2C BUS EEPROM (2-Wire), TSSOP-B8 BR24G32FVT-3AGE2 Texas Instruments
U4 1 10-MHz, RRIO, CMOS Operational Amplifier for Cost-Sensitive Systems,
DBV0005A (SOT-23-5)
TLV9061IDBVR Texas Instruments
