Data Flash Summary
Table 19-1. Data Flash Summary Table (continued)
Class Subclass Address Name Type Min Value Max Value Default Units
Settings Protection 0x44CB
Enabled Removal
Recovery B
H1 0x0 0x40 0x0 Hex
Settings
Permanent
Failure
0x451D Enabled PF A H1 0x0 0xFF 0x0 Hex
Settings
Permanent
Failure
0x451E Enabled PF B H1 0x0 0xFF 0x0 Hex
Settings Configuration 0x445F FET Options H2 0x0 0x03FF 0x0021 Hex
Settings Configuration 0x4461
Sbs Gauging
Configuration
H1 0x0 0x83 0x0 Hex
Settings Configuration 0x4462 Smb Configuration H1 0x0 0xB7 0xA0 Hex
Settings Configuration 0x4472 Power Config H1 0x0 0x01 0x00 Hex
Settings Configuration 0x448C LED Configuration H1 0x0 0xFF 0x00 Hex
Settings Configuration 0x44A9 Temperature Enable H1 0x0 0x1F 0x09 Hex
Settings Configuration 0x44AA Temperature Mode H1 0x0 0x07 0x0 Hex
Settings Configuration 0x44AB DA Configuration H1 0x0 0xDF 0x11 Hex
Settings Configuration 0x44AC AFE Cell Map H2 0x0 0x7FFF 0x0013 Hex
Settings Configuration 0x458B
CEDV Gauging
Configuration
H2 0x0 0x07FF 0x0002 Hex
Settings Configuration 0x45D4 SOC Flag Config H2 0x0 0x13FF 0x02FB Hex
Settings Configuration 0x460C Balancing Configuration H1 0x0 0xFF 0x01 Hex
Settings Fuse 0x4458 PF SAFE A H1 0x0 0xFF 0x0 Hex
Settings Fuse 0x4459 PF SAFE B H1 0x0 0xFF 0x0 Hex
Settings Fuse 0x445A PF SAFE C H1 0x0 0x03 0x0 Hex
Settings Fuse 0x445E Fuse Blow Timeout U1 0 255 30 s
Settings
Aux SMB
Address
0x4463 Addr Reads U1 0 10 3 —
Settings
Aux SMB
Address
0x4464 SMBTAR_ADDR0 H1 0x0 0xFF 0x20 Hex
Settings
Aux SMB
Address
0x4465 SMBTAR_ADDR1 H1 0x0 0xFF 0x22 Hex
Settings
Aux SMB
Address
0x4466 SMBTAR_ADDR2 H1 0x0 0xFF 0x24 Hex
Settings
Aux SMB
Address
0x4467 SMBTAR_ADDR3 H1 0x0 0xFF 0x25 Hex
Settings
Aux SMB
Address
0x4468 SMBTAR_ADDR4 H1 0x0 0xFF 0x26 Hex
Settings
Aux SMB
Address
0x4469 SMBTAR_ADDR5 H1 0x0 0xFF 0x28 Hex
Settings
Aux SMB
Address
0x446A SMBTAR_ADDR6 H1 0x0 0xFF 0x2A Hex
Settings
Aux SMB
Address
0x446B SMBTAR_ADDR7 H1 0x0 0xFF 0x2C Hex
Settings
SMB Master
Mode
0x446E Host Address H1 0x0 0xFF 0x10 Hex
Settings
SMB Master
Mode
0x446F Charger Address H1 0x0 0xFF 0x12 Hex
Settings
SMB Master
Mode
0x4470 Alarm Timer U1 10 255 10 s
Settings
SMB Master
Mode
0x4471 Charger Request Timer U1 10 255 50 s
Settings Manufacturing 0x42C8 Mfg Status init H2 0x0 0xFFFF 0x0000 Hex
Protections CUV 0x44CC Threshold I2 0 32767 2500 mV
Protections CUV 0x44CE Delay U1 0 255 2 s
Protections CUV 0x44CF Recovery I2 0 32767 3000 mV
Protections COV 0x44D1 Threshold I2 0 32767 4300 mV
Protections COV 0x44D3 Delay U1 0 255 2 s
Protections COV 0x44D4 Recovery I2 0 32767 4100 mV
