Data Flash Summary
Table 19-1. Data Flash Summary Table (continued)
Class Subclass Address Name Type Min Value Max Value Default Units
Protections OCC 0x44D6 Threshold I2 –32768 32767 6000 mA
Protections OCC 0x44D8 Delay U1 0 255 6 s
Protections OCC 0x44D9 Recovery Threshold I2 –32768 32767 –200 mA
Protections OCC 0x44DB Recovery Delay U1 0 255 5 s
Protections OCD 0x44DC Threshold I2 –32768 32767 –6000 mA
Protections OCD 0x44DE Delay U1 0 255 6 s
Protections OCD 0x44DF Recovery Threshold I2 –32768 32767 200 mA
Protections OCD 0x44E1 Recovery Delay U1 0 255 5 s
Protections OCDL 0x44E2 Latch Limit U1 0 255 5 —
Protections OCDL 0x44E3 Counter Dec Delay U1 0 255 10 s
Protections OCDL 0x44E4 Reset U1 0 255 15 s
Protections AOLD 0x44B1 Threshold and Delay H1 0x0 0xFF 0x00 Hex
Protections AOLD 0x44E5 Latch Limit U1 0 255 0 —
Protections AOLD 0x44E6 Counter Dec Delay U1 0 255 10 s
Protections AOLD 0x44E7 Recovery U1 0 255 5 s
Protections AOLD 0x44E8 Reset U1 0 255 15 s
Protections ASCD 0x44B0 Threshold and Delay H1 0x0 0xFF 0x00 Hex
Protections ASCD 0x44E9 Latch Limit U1 0 255 0 —
Protections ASCD 0x44EA Counter Dec Delay U1 0 255 10 s
Protections ASCD 0x44EB Recovery U1 0 255 5 s
Protections ASCD 0x44EC Reset U1 0 255 15 s
Protections OTC 0x44ED Threshold I2 –400 1500 550 0.1°C
Protections OTC 0x44EF Delay U1 0 255 2 s
Protections OTC 0x44F0 Recovery I2 –400 1500 500 0.1°C
Protections OTD 0x44F2 Threshold I2 –400 1500 600 0.1°C
Protections OTD 0x44F4 Delay U1 0 255 2 s
Protections OTD 0x44F5 Recovery I2 –400 1500 550 0.1°C
Protections OTF 0x44F7 Threshold I2 –400 1500 800 0.1°C
Protections OTF 0x44F9 Delay U1 0 255 2 s
Protections OTF 0x44FA Recovery I2 –400 1500 650 0.1°C
Protections UTC 0x44FC Threshold I2 –400 1500 0 0.1°C
Protections UTC 0x44FE Delay U1 0 255 2 s
Protections UTC 0x44FF Recovery I2 –400 1500 50 0.1°C
Protections UTD 0x4501 Threshold I2 –400 1500 0 0.1°C
Protections UTD 0x4503 Delay U1 0 255 2 s
Protections UTD 0x4504 Recovery I2 –400 1500 50 0.1°C
Protections
AFE External
Override
0x4506 Delay U1 0 255 5 s
Protections
AFE External
Override
0x4507 Recovery U1 0 255 2 s
Protections PTO 0x4508 Charge Threshold I2 –32768 32767 2000 mA
Protections PTO 0x450A Suspend Threshold I2 –32768 32767 1800 mA
Protections PTO 0x450C Delay U2 0 65535 1800 s
Protections PTO 0x450E Reset I2 0 32767 2 mAh
Protections CTO 0x4510 Charge Threshold I2 –32768 32767 2500 mA
Protections CTO 0x4512 Suspend Threshold I2 –32768 32767 2000 mA
Protections CTO 0x4514 Delay U2 0 65535 54000 s
Protections CTO 0x4516 Reset I2 0 32767 2 mAh
Protections OC 0x4518 Threshold I2 –32768 32767 300 mAh
Protections OC 0x451A Recovery I2 –32768 32767 2 mAh
Protections OC 0x451C RSOC Recovery U1 0 100 90 %
