Texas Instruments bq78350-R1 Technical Reference

www.ti.com
149
SLUUBD3D–September 2015–Revised September 2018
Submit Documentation Feedback
Copyright © 2015–2018, Texas Instruments Incorporated
Data Flash Summary
Table 19-1. Data Flash Summary Table (continued)
Class Subclass Address Name Type Min Value Max Value Default Units
Permanent
Fail
SOCC 0x4521 Threshold I2 –32768 32767 10000 mA
Permanent
Fail
SOCC 0x4523 Delay U1 0 255 5 s
Permanent
Fail
SOCD 0x4524 Threshold I2 –32768 32767 –10000 mA
Permanent
Fail
SOCD 0x4526 Delay U1 0 255 5 s
Permanent
Fail
SOT 0x4527 Threshold I2 –400 1500 650 0.1°C
Permanent
Fail
SOT 0x4529 Delay U1 0 255 5 s
Permanent
Fail
SOTF 0x452A Threshold I2 –400 1500 1000 0.1°C
Permanent
Fail
SOTF 0x452C Delay U1 0 255 5 s
Permanent
Fail
Open
Thermistor
0x452D Threshold I2 0 32767 2232 0.1°K
Permanent
Fail
Open
Thermistor
0x452F Delay U1 0 255 5 s
Permanent
Fail
VIMR 0x4530 Check Voltage I2 0 5000 3500 mV
Permanent
Fail
VIMR 0x4532 Check Current I2 0 32767 10 mA
Permanent
Fail
VIMR 0x4534 Delta Threshold I2 0 5000 500 mV
Permanent
Fail
VIMR 0x4536 Delta Delay U1 0 255 5 s
Permanent
Fail
VIMR 0x4537 Duration U2 0 65535 100 s
Permanent
Fail
CFET 0x4539 OFF Threshold I2 0 500 5 mA
Permanent
Fail
CFET 0x453B OFF Delay U1 0 255 5 s
Permanent
Fail
DFET 0x453C OFF Threshold I2 –500 0 –5 mA
Permanent
Fail
DFET 0x453E OFF Delay U1 0 255 5 s
Permanent
Fail
AFER 0x453F Threshold U1 0 255 100 —
Permanent
Fail
AFER 0x4540 Delay Period U1 0 255 2 s
Permanent
Fail
AFER 0x4541 Compare Period U1 0 255 5 s
Permanent
Fail
AFEC 0x4542 Threshold U1 0 255 100 —
Permanent
Fail
AFEC 0x4543 Delay Period U1 0 255 5 s
Permanent
Fail
AFE XREADY 0x4544 Threshold U1 0 255 100 —
Permanent
Fail
AFE XREADY 0x4545 Delay Period U1 0 255 5 s
Permanent
Fail
AFE External
Override
0x4546 Delay U1 0 255 20 s
Permanent
Fail
AFE SOV/AFE
SUV
0x44B2 SOV and SUV Delay H1 0x0 0xFF 0x50 Hex
Permanent
Fail
AFE SOV 0x44B7 Threshold I2 3150 4700 4350 mV
Permanent
Fail
AFE SUV 0x44B9 Threshold I2 1580 3100 1750 mV
Charge
Algorithm
Temperature
Ranges
0x45DF
Charge Inhibit/Suspend
Low Temp
I1 –128 127 0 °C
