Data Flash Summary
Table 19-1. Data Flash Summary Table (continued)
Class Subclass Address Name Type Min Value Max Value Default Units
Fuel Gauging CEDV cfg 0x4591 R0 U2 0 65535 867 —
Fuel Gauging CEDV cfg 0x4593 T0 U2 0 65535 4030 —
Fuel Gauging CEDV cfg 0x4595 R1 U2 0 65535 316 —
Fuel Gauging CEDV cfg 0x4597 TC U1 0 255 9 —
Fuel Gauging CEDV cfg 0x4598 C1 U1 0 255 0 —
Fuel Gauging CEDV cfg 0x4599 Age Factor U1 0 255 0 —
Fuel Gauging CEDV cfg 0x459A Fixed EDV 0 I2 0 32767 3031 —
Fuel Gauging CEDV cfg 0x459C EDV 0 Hold Time U1 1 255 1 s
Fuel Gauging CEDV cfg 0x459D Fixed EDV 1 I2 0 32767 3385 —
Fuel Gauging CEDV cfg 0x459F EDV 1 Hold Time U1 1 255 1 s
Fuel Gauging CEDV cfg 0x45A0 Fixed EDV 2 I2 0 32767 3501 —
Fuel Gauging CEDV cfg 0x45A2 EDV 2 Hold Time U1 1 255 1 s
Fuel Gauging CEDV cfg 0x45A7 Battery Low % U2 0 65535 700 .01%
Fuel Gauging CEDV cfg 0x45AB Min Delta V Filter I2 0 32767 10 mV
Fuel Gauging CEDV cfg 0x45AD FCC Learn Up I2 0 32767 512 mAh
Fuel Gauging CEDV cfg 0x45AF FCC Learn Down I2 0 32767 256 mAh
Fuel Gauging CEDV cfg 0x45B4 Learning Low Temp I2 –100 32767 119 0.1°C
Fuel Gauging CEDV cfg 0x45BD
Requested Learning
cycle count
U1 0 255 20 Num
Fuel Gauging CEDV cfg 0x45BE OverLoad Current I2 0 32767 5000 mA
Fuel Gauging CEDV cfg 0x45C2 Self Discharge Rate U1 0 255 20 0.01%/day
Fuel Gauging CEDV cfg 0x45C3 Electronics Load I2 0 255 0 3 μA
Fuel Gauging CEDV cfg 0x45C5 Near Full I2 0 32767 200 mAh
Fuel Gauging CEDV cfg 0x45C7 Reserve Capacity I2 0 32767 0 mAh
Fuel Gauging CEDV cfg 0x45CB RemCap Init Percent U1 0 110 100 %
Power Power 0x4473 Valid Update Voltage I2 0 32767 3500 mV
Power Shutdown 0x4475 Shutdown Voltage I2 0 32767 1750 mV
Power Shutdown 0x4477 Shutdown Time U1 0 255 10 s
Power Shutdown 0x4478 PF Shutdown Voltage I2 0 32767 1750 mV
Power Shutdown 0x447A PF Shutdown Time U1 0 255 10 s
Power Shutdown 0x447B
Charger Present
Threshold
I2 0 32767 3000 mV
Power Sleep 0x447D Sleep Current I2 0 32767 10 mA
Power Sleep 0x447F Bus Timeout U1 0 255 5 s
Power Sleep 0x4484 Voltage Time U1 0 255 5 s
Power Sleep 0x4485 Current Time U1 0 255 20 s
Power Ship 0x4487 FET Off Time U1 0 127 10 s
Power Ship 0x4488 Delay U1 0 254 20 s
Power Ship 0x4489 Auto Ship Time U2 0 65535 1440 min
Power KEYIN 0x448B Time U1 0 10 2 s
PF Status
Device Status
Data
0x41C0 Safety Alert A H1 0x0 0xFF 0x0 Hex
PF Status
Device Status
Data
0x41C1 Safety Status A H1 0x0 0xFF 0x0 Hex
PF Status
Device Status
Data
0x41C2 Safety Alert B H1 0x0 0xFF 0x0 Hex
PF Status
Device Status
Data
0x41C3 Safety Status B H1 0x0 0xFF 0x0 Hex
PF Status
Device Status
Data
0x41C4 Safety Alert C H1 0x0 0xFF 0x0 Hex
PF Status
Device Status
Data
0x41C5 Safety Status C H1 0x0 0xFF 0x0 Hex
PF Status
Device Status
Data
0x41C8 PF Alert A H1 0x0 0xFF 0x0 Hex
