Data Flash Summary
Table 19-1. Data Flash Summary Table (continued)
Class Subclass Address Name Type Min Value Max Value Default Units
PF Status
Device Status
Data
0x41C9 PF Status A H1 0x0 0xFF 0x0 Hex
PF Status
Device Status
Data
0x41CA PF Alert B H1 0x0 0xFF 0x0 Hex
PF Status
Device Status
Data
0x41CB PF Status B H1 0x0 0xFF 0x0 Hex
PF Status
Device Status
Data
0x41CC PF Alert C H1 0x0 0xFF 0x0 Hex
PF Status
Device Status
Data
0x41CD PF Status C H1 0x0 0xFF 0x0 Hex
PF Status
Device Status
Data
0x41D0 Fuse Flag H2 0x0 0xFFFF 0x0 Hex
PF Status
Device Status
Data
0x41D2 Operation Status A H2 0x0 0xFFFF 0x0 Hex
PF Status
Device Status
Data
0x41D4 Operation Status B H2 0x0 0xFFFF 0x0 Hex
PF Status
Device Status
Data
0x41D6 Temp Range H1 0x0 0xFF 0x0 Hex
PF Status
Device Status
Data
0x41D7 Charging Status H1 0x0 0xFF 0x0 Hex
PF Status
Device Status
Data
0x41D8 Gauging Status H1 0x0 0xFF 0x0 Hex
PF Status
Device Status
Data
0x41D9 CEDV Status H1 0x0 0xFF 0x0 Hex
PF Status
Device
Voltage Data
0x41DA Cell 1 Voltage I2 –32768 32767 0 mV
PF Status
Device
Voltage Data
0x41DC Cell 2 Voltage I2 –32768 32767 0 mV
PF Status
Device
Voltage Data
0x41DE Cell 3 Voltage I2 –32768 32767 0 mV
PF Status
Device
Voltage Data
0x41E0 Cell 4 Voltage I2 –32768 32767 0 mV
PF Status
Device
Voltage Data
0x41E2 Cell 5 Voltage I2 –32768 32767 0 mV
PF Status
Device
Voltage Data
0x41E4 Cell 6 Voltage I2 –32768 32767 0 mV
PF Status
Device
Voltage Data
0x41E6 Cell 7 Voltage I2 –32768 32767 0 mV
PF Status
Device
Voltage Data
0x41E8 Cell 8 Voltage I2 –32768 32767 0 mV
PF Status
Device
Voltage Data
0x41EA Cell 9 Voltage I2 –32768 32767 0 mV
PF Status
Device
Voltage Data
0x41EC Cell 10 Voltage I2 –32768 32767 0 mV
PF Status
Device
Voltage Data
0x41EE Cell 11 Voltage I2 –32768 32767 0 mV
PF Status
Device
Voltage Data
0x41F0 Cell 12 Voltage I2 –32768 32767 0 mV
PF Status
Device
Voltage Data
0x41F2 Cell 13 Voltage I2 –32768 32767 0 mV
PF Status
Device
Voltage Data
0x41F4 Cell 14 Voltage I2 –32768 32767 0 mV
PF Status
Device
Voltage Data
0x41F6 Cell 15 Voltage I2 –32768 32767 0 mV
PF Status
Device
Voltage Data
0x41FA Battery Direct Voltage I2 –32768 32767 0 mV
PF Status
Device Current
Data
0x41FE Current I2 –32768 32767 0 mA
PF Status
Device
Temperature
Data
0x4200 TS1 Temperature I2 –32768 32767 0 0.1°K
