Data Flash Summary
Table 19-1. Data Flash Summary Table (continued)
Class Subclass Address Name Type Min Value Max Value Default Units
PF Status
Device
Temperature
Data
0x4202 TS2 Temperature I2 –32768 32767 0 0.1°K
PF Status
Device
Temperature
Data
0x4204 TS3 Temperature I2 –32768 32767 0 0.1°K
PF Status
Device
Temperature
Data
0x4206
Gauge Internal
Temperature
I2 –32768 32767 0 0.1°K
PF Status AFE Regs 0x4208 AFE SYS Stat H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x4209 AFE Cell Balance1 H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x420A AFE Cell Balance2 H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x420B AFE Cell Balance3 H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x420C AFE Sys Control1 H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x420D AFE Sys Control2 H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x420E AFE Protection1 H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x420F AFE Protection2 H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x4210 AFE Protection3 H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x4211 AFE OV Trip H1 0x0 0xFF 0x0 Hex
PF Status AFE Regs 0x4212 AFE UV Trip H1 0x0 0xFF 0x0 Hex
Black Box Safety Status 0x4180 1st Status Status A H1 0x0 0xFF 0x0 Hex
Black Box Safety Status 0x4181 1st Status Status B H1 0x0 0xFF 0x0 Hex
Black Box Safety Status 0x4182 1st Safety Status C H1 0x0 0xFF 0x0 Hex
Black Box Safety Status 0x4184 1st Time to Next Event U1 0 255 0 s
Black Box Safety Status 0x4185 2nd Status Status A H1 0x0 0xFF 0x0 Hex
Black Box Safety Status 0x4186 2nd Status Status B H1 0x0 0xFF 0x0 Hex
Black Box Safety Status 0x4187 2nd Safety Status C H1 0x0 0xFF 0x0 Hex
Black Box Safety Status 0x4189 2nd Time to Next Event U1 0 255 0 s
Black Box Safety Status 0x418A 3rd Status Status A H1 0x0 0xFF 0x0 Hex
Black Box Safety Status 0x418B 3rd Status Status B H1 0x0 0xFF 0x0 Hex
Black Box Safety Status 0x418C 3rd Safety Status C H1 0x0 0xFF 0x0 Hex
Black Box Safety Status 0x418E 3rd Time to Next Event U1 0 255 0 s
Black Box PF Status 0x418F 1st PF Status A H1 0x0 0xFF 0x0 Hex
Black Box PF Status 0x4190 1st PF Status B H1 0x0 0xFF 0x0 Hex
Black Box PF Status 0x4191 1st PF Status C H1 0x0 0xFF 0x0 Hex
Black Box PF Status 0x4193 1st Time to Next Event U1 0 255 0 s
Black Box PF Status 0x4194 2nd PF Status A H1 0x0 0xFF 0x0 Hex
Black Box PF Status 0x4195 2nd PF Status B H1 0x0 0xFF 0x0 Hex
Black Box PF Status 0x4196 2nd PF Status C H1 0x0 0xFF 0x0 Hex
Black Box PF Status 0x4198 2nd Time to Next Event U1 0 255 0 s
Black Box PF Status 0x4199 3rd PF Status A H1 0x0 0xFF 0x0 Hex
Black Box PF Status 0x419A 3rd PF Status B H1 0x0 0xFF 0x0 Hex
Black Box PF Status 0x419B 3rd PF Status C H1 0x0 0xFF 0x0 Hex
Black Box PF Status 0x419D 3rd Time to Next Event U1 0 255 0 s
System Data
Manufacturer
Data
0x4040
Manufacturer Info A
Length
U1 1 32 32 —
System Data
Manufacturer
Data
0x4041
Manufacturer Info Block
A01
H1 0x0 0xFF 0x61 Hex
System Data
Manufacturer
Data
0x4042
Manufacturer Info Block
A02
H1 0x0 0xFF 0x62 Hex
System Data
Manufacturer
Data
0x4043
Manufacturer Info Block
A03
H1 0x0 0xFF 0x63 Hex
System Data
Manufacturer
Data
0x4044
Manufacturer Info Block
A04
H1 0x0 0xFF 0x64 Hex
