Host Controlled GPIO
LED1 (Bit 1): GPIO 1
1 = Active as GPIO
0 = Inactive (used as LED1)
RSVD (Bit 0): Reserved
Table 14-2. Host Controlled GPIO Output Enable Configuration
Class Subclass Name Format Min Max Default Unit
GPIO GPIO Config
GPIO Output
Enable
Hex 0x00 0xFE 0x00 —
7 6 5 4 3 2 1 0
GPIO B GPIO A LED5 LED4 LED3 LED2 LED1 RSVD
GPIO B (Bit 7): GPIO B
1 = Output
0 = Input
GPIO A (Bit 6): GPIO A
1 = Output
0 = Input
LED5 (Bit 5): GPIO 5
1 = Output
0 = Input
LED4 (Bit 4): GPIO 4
1 = Output
0 = Input
LED3 (Bit 3): GPIO 3
1 = Output
0 = Input
LED2 (Bit 2): GPIO 2
1 = Output
0 = Input
LED1 (Bit 1): GPIO 1
1 = Output
0 = Input
RSVD (Bit 0): Reserved
Table 14-3. Host Controlled GPIO Output Default Configuration
Class Subclass Name Format Min Max Default Unit
GPIO GPIO Config
GPIO Output
Default
Hex 0x00 0xFE 0x00 —
7 6 5 4 3 2 1 0
GPIO B GPIO A LED5 LED4 LED3 LED2 LED1 RSVD
