Target device
MSP430FR2355
Crystal
32.768 kHz
Micro-B
USB
3.3-V LDO
ESD
Protection
Debug
MCU
LED
Red, Green
Crystal
4 MHz
UART, SBW to Target
User interface
2 buttons, 2 LEDs
40-pin
LaunchPad
standard headers
Power to Target
Reset
button
EnergyTrace
Technology
Grove
Connector
Ambient Light
Sensor
Hardware www.ti.com
6
SLAU680–May 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
MSP430FR2355 LaunchPad™ Development Kit (MSP ‑ EXP430FR2355)
2 Hardware
Figure 2 shows an overview of the MSP-EXP430FR2355 hardware.
Figure 2. MSP-EXP430FR2355 Overview
2.1 Block Diagram
Figure 3 shows the block diagram.
Figure 3. MSP-EXP430FR2355 Block Diagram
