5-19
Note:
Non-poin
ter typ
e functio
n argum
ents to log_
printf n
eed expl
icit type
castin
g
to (Arg)
as shown
in the foll
owing co
de exampl
e:
LOG_printf(&trace, "Task %d Done", (Ar
g)id);
Figure 5-3.
Trace Result
s from Example 5-18
200
202
