Table 6-41 provides a summary of the McBSP registers.
Table 6-41. McBSP Register Summary
NAME
McBSP-A
ADDRESS
TYPE RESET VALUE DESCRIPTION
Data Registers, Receive, Transmit
DRR2 0x5000 R 0x0000 McBSP Data Receive Register 2
DRR1 0x5001 R 0x0000 McBSP Data Receive Register 1
DXR2 0x5002 W 0x0000 McBSP Data Transmit Register 2
DXR1 0x5003 W 0x0000 McBSP Data Transmit Register 1
McBSP Control Registers
SPCR2 0x5004 R/W 0x0000 McBSP Serial Port Control Register 2
SPCR1 0x5005 R/W 0x0000 McBSP Serial Port Control Register 1
RCR2 0x5006 R/W 0x0000 McBSP Receive Control Register 2
RCR1 0x5007 R/W 0x0000 McBSP Receive Control Register 1
XCR2 0x5008 R/W 0x0000 McBSP Transmit Control Register 2
XCR1 0x5009 R/W 0x0000 McBSP Transmit Control Register 1
SRGR2 0x500A R/W 0x0000 McBSP Sample Rate Generator Register 2
SRGR1 0x500B R/W 0x0000 McBSP Sample Rate Generator Register 1
Multichannel Control Registers
MCR2 0x500C R/W 0x0000 McBSP Multichannel Register 2
MCR1 0x500D R/W 0x0000 McBSP Multichannel Register 1
RCERA 0x500E R/W 0x0000 McBSP Receive Channel Enable Register Partition A
RCERB 0x500F R/W 0x0000 McBSP Receive Channel Enable Register Partition B
XCERA 0x5010 R/W 0x0000 McBSP Transmit Channel Enable Register Partition A
XCERB 0x5011 R/W 0x0000 McBSP Transmit Channel Enable Register Partition B
PCR 0x5012 R/W 0x0000 McBSP Pin Control Register
RCERC 0x5013 R/W 0x0000 McBSP Receive Channel Enable Register Partition C
RCERD 0x5014 R/W 0x0000 McBSP Receive Channel Enable Register Partition D
XCERC 0x5015 R/W 0x0000 McBSP Transmit Channel Enable Register Partition C
XCERD 0x5016 R/W 0x0000 McBSP Transmit Channel Enable Register Partition D
RCERE 0x5017 R/W 0x0000 McBSP Receive Channel Enable Register Partition E
RCERF 0x5018 R/W 0x0000 McBSP Receive Channel Enable Register Partition F
XCERE 0x5019 R/W 0x0000 McBSP Transmit Channel Enable Register Partition E
XCERF 0x501A R/W 0x0000 McBSP Transmit Channel Enable Register Partition F
RCERG 0x501B R/W 0x0000 McBSP Receive Channel Enable Register Partition G
RCERH 0x501C R/W 0x0000 McBSP Receive Channel Enable Register Partition H
XCERG 0x501D R/W 0x0000 McBSP Transmit Channel Enable Register Partition G
XCERH 0x501E R/W 0x0000 McBSP Transmit Channel Enable Register Partition H
MFFINT 0x5023 R/W 0x0000 McBSP Interrupt Enable Register
