Premier 412/816/832 Installation Manual System Overview
INS159 5
• Fully adjustable back-lighting, normally bright, dim or
off, changing to bright whenever a keypad is used and
during the entry mode
• Dedicated status lights for “Alarm”, “Service”, “Armed”,
“Ready”, “Fire”, “Bypass”, “Instant” and “Stay”
Premier LCD/L
The Premier LCD remote keypad has a standard 32
character back-lit LCD display, whereas the Premier LCDL
has a large 32 character back-lit LCD display.
• 2 programmable EOL zones
• 1 programmable low current (100mA) output
• 4-wire connection to data network.
• Built in piezoelectric sounder.
• Fully adjustable back-lighting, normally bright, dim or
off, changing to bright whenever a keypad is used and
during the entry mode
• Dedicated status lights for “Power”, “Armed”, “Ready”,
“Service” and “Bypass”
• Speaker driver output (Premier LCDL Only).
Premier LCDLP
• Premier LCDL keypad with built-in proximity tag reader
Premier LCDP
• Premier LCD keypad with built-in proximity tag reader
Zone Expansion Modules
Either system can be expanded using one of the following
zone expansion modules:
Premier 8X Remote Zone Expander
This module comes supplied in its own enclosure and is
connected to the control panel data network to provide
remote expansion of the system. This module provides the
following additional facilities:
• 8 programmable EOL zones
• 2 programmable low current (100mA) outputs
• Speaker driver output with electronic volume control.
Premier 8XE Local Zone Expander
This module comes supplied as a PCB and simply plugs
onto the main control panel circuit board. This module
provides 8 programmable EOL zones.
PC-Com Module
This module plugs on to the Premier 412, 816 and Premier
832 control panel to provide an RS232 interface, which can
be used for:
• Connection of a serial printer to print the event log
• Upload/download the system programming via Wintex
UDL software and PC.
ComIP Module
This module plugs on to Com1 of the control panel to
provide the following:
• Alarm event reporting via TCP/IP (WAN/LAN).
• High speed upload/download of system programming
via WAN/LAN using Wintex UDL software.
Speech Module
This module plugs on to the control panel to provide the
following:
• 2 recordable messages (12 seconds each).
• Each message can be assigned to a specific output
function, e.g. Alarm or Fire.
This manual does not cover the full installation of this device;
please refer to the instructions supplied with the Speech
Module.
Radio Receiver Module
The control panel will accept either the Texecom RadioPlus
receiver module and radio devices or the Inovonics EE4000
radio receiver and ES1200 series devices. The receiver
module plugs on to Com1 of the control panel to provide the
following:
• 32 wireless devices, such as PIR, Door Contacts,
Remote FOBs etc.
• RF supervision of each device.
• Battery supervision of each device.
This manual does not cover the full installation of these
devices; please refer to the instructions supplied with the
radio receiver module.
