Wire Harness Installation (Continued)
4’
7’
(P# P0086)
RING TERMINAL
5/16” STUD SIZE
(P# P0106)
FEMALE DISCONNECT
(P# P0086)
RING TERMINAL
5/16” STUD SIZE
(P# P0106)
FEMALE DISCONNECT
(P# P0280)
2 WAY METRI-PACK
280 SEALED MALE CONNECTOR
Figure B
SWITCH
(P#J2001)
FRONT
RIGHT
SWITCH TERMINAL (A)
SWITCH TERMINAL (B)
