Textron Jacobsen Pro12 DFS - Page 30

30
A2059_01 Clutch Sub-Assembly
7
8
4
3
5
1
6
2
Item # Part # Desc. Qty.
1 M0001 Electric Clutch 1
2 S0007 Clutch Shaft 1
3 K0278 Double Indented Washer 7/16" / 1.375 OD x .440 ID x .179 T 1
4 K0140 Lock Washer 7/16" / High-Collar Helical Spring 1
5 K0359 HHCS / 7/16"-20 x 4.00" w/ Patch 1
6 M0309 A-Section Pulley / 4.75 OD 1
7 S0221 Eng. Pulley Bushing #27 1
8 K0076 Key 1/4" x 3/4" Long 1
(Ogura 110 Ft-Lb Clutch/Brake)
