INDEX DESCRIPTION QTY PART #
1 WIRE SKIRT RETAINER 2 Y4661
2 1/4-20 X 1/2 BUTTON HEAD SCREW 6 VT25-20BH500
3 .375 OD LOOP CLAMP STAINLESS 2 Y4655
4 LOWER WIRE SKIRT 1 Y4660
5 CABLE - POWER & COMM. 30' Y5200
6 UPPER WIRE SKIRT 1 Y4650
7 CYLINDER NUT 2 Y4437
8
4" MONITOR BASE CLAMP
2
Y4435
3" MONITOR BASE CLAMP Y4436
9 10-32 X 1 1/4 SOCKET HEAD SCREW 2 VT10-32SH1.2
10 WASHER 2 VW360X200-04
11
VO-RING-244
1
VO-244
VO-RING-236 VO-236
12 OVERRIDE KNOB 2 Z245
13 OVERRIDE KNOB LABEL 2 Y4176
14 1/4-28 X 1/2 SOCKET HEAD SCREW 3 VT25-28SH500
15 CONTROL BOX BRACKET 1 Y4622
16 3/8-24 X 1-1/4 SOCKET HEAD SCREW 2 VT37-24SH1.2
17 CRANK BUSHING 2 A1513
18 10-24 X 3/8 BUTTON HEAD SCREW 1 VT10-24BH375
19 .500 OD LOOP CLAMP STAINLESS 1 Y4657
20 1/4-28 X 5/8 SOCKET HEAD SCREW 8 VT25-28SH625
A CONTROL BOX SUBASSEMBLY 1 SEE SECTION 9.4
B MOTOR ENCLOSURE SUBASSEMBLY 2 SEE SECTION 9.5
* - Length Depends on Confi guration.
