AS 680/682
Installation and Setup Description, Operation and Maintenance
ADS−B
3−34 Ed. 10.07
5. Receiver Unit (RXU)
Ground Station 1 RXU Ground Station 2 RXU
RXU Offset: DIP−switch Settings: DIP−switch Settings:
j DSO Screenshot available j DSO Screenshot available
RXU/SW2 jjjj Off
jjjj On
1 2 3 4
jjjj Off
jjjj On
1 2 3 4
6. RF Cables
Ground Station 1 Ground Station 2
Cable Insertion Loss VSWR Insertion Loss VSWR
ADS−B Ant. – AAU
ADS−B AAU – Shltr
ADS−B Shltr – Rck
SM Ant. – Shelter
7. Technical System Control (TSC) – Site Monitor Settings
On TSC Site Monitor 1 Site Monitor 2 (if available)
Mode S ID (own)
Mode S ID (other)
Actual Site Monitor
RX Level
Site Monitor RX
Threshold
8. Ground Station Settings
Ground Station 1 Ground Station 2
GS Settings j Configuration exported
j TSC Screenshots available
j Configuration exported
j TSC Screenshots available
9. Notes
Name Date Signature
Page 2 of 2
