SITE INSTALLATION REPORT (SIR)
SITE Site Name Callsign
1. Basic Parameters
On TSC Ground Station 1 Ground Station 2
Callsign
SIC
IP Address
Latitude
Longitude
SPU S/N
2. ADS−B Antennas
ADS−B Antenna 1 ADS−B Antenna 2 (if available)
Type
S/N
VSWR
Height
Additionally
available
j Sketch of Configuration
j Installation Photo
j 360° Panorama
j Sketch of Configuration
j Installation Photo
j 360° Panorama
3. Antenna Amplifier Unit (AAU)
AAU AAU 1 AAU 2 (if available)
AAU S/N
DC Voltage
4. GPS Antenna
GPS GPS Antenna 1 GPS Antenna 2
Height
Additionally
available
j Sketch of Configuration
j Installation Photo
j 360° Panorama
j Sketch of Configuration
j Installation Photo
j 360° Panorama
DC Voltage
