AS 680/682
Description, Operation and Maintenance Subsystem Description
ADS−B
2−11Ed. 10.07
Board Indicator Color Control Function of control or indicator (lit or flashing)
SBC cont. LED, USR (0/1)*
LED, USR (2/3)*
Ethernet conn. LED:
Speed
LINK/ACT
red
green
red
green
green
yellow
green
yellow
The function of this LED is programmable by
software and depends on the operating
system. Not used.
The function of this LED is software
programmable and depends on the operating
system. Not used.
Lit:active connection at 100 Mbps; off:10 Mbps
Spare/reserved
Lit: indicates an active connection; blinking:
indicates transmit or receive activity
Off: Indicates no active connection
* These LED are bi−color LED (green/red)
NOTE: The small Abort/Reset key switch (ABT − idle − RST) is normally not used. The neutral
position is mid (idle). "RST" (move to right position) would initiate a reset of the processor
board and thus a reboot of the system software. "ABT" (move to left position) is intended
to interrupt program execution and to call a separate custom routine.
In the AS 680 Ground Station this custom routine does not exist nor is there any intended
use for this switch. Therefore actuating it would just stop the Ground Station from opera-
tion without a reboot.
CAUTION
Do not actuate the key switch to the left position "ABT". Avoid to actuate it accidentally.
