AS 680/682
Installation and Setup Description, Operation and Maintenance
ADS−B
3−8 Ed. 10.07
SPU subrack, rear
AC−Power
Equipped with AC/DC−converter
Mains switch AC
AC, 0.8AT/250V (2x)
Mains fuse
VAC 85V...264V
0
I
mains
nom. 230 VAC
PE
Fig. 3−13 AS 682, SPU power connection rear side
Fuse 10 A
Mains sockets
230 VAC
Mains terminals
Fuse 10 A
SPU1
SPU2
Mains sockets
230 VAC
SM1/DC
Data switch, front
cabinet rear, top
cabinet rear, bottom
SPU2
SPU1
RJ45 Ethernet
SNMP
RJ45 Ethernet, SNMP
PE
Cabinet door switch
rear front
UPS XS 1000, rear (1)
UPS Ext. rear
Mains sockets 9x
230 VAC
cabinet front, bottom
AC/DC conv.
plug−in
RJ45 Ethernet, SNMP (UPS 1 and 2)
1) Provided by customer
1)
RJ45 Ethernet
to ADS−B Network
Earth bar
RJ45 Ethernet
SNMP
UPS XS 1000, rear (2)
doors
Status
to SPU 1 ,2
UPS Ext. rear
Fig. 3−14 System cabling ADS−B Ground Station AS 682, Data Switch and UPS (2)
