AS 680/682
Installation and Setup Description, Operation and Maintenance
ADS−B
3−30 Ed. 10.07
30 Note the hex value given within the last column. This is the actual relative signal strength with which
the site monitor signal is received by the Ground Station. Log it into the SIR.
31 Stop the recording by either clicking on the black square below the File menu or by selecting
menu Command|Stop .
32 Quit the RRC application using the File|Exit menu item.
33 Change the visible desktop window by selecting one of the blue areas within the desktop panel
at the bottom of the desktop. Select the window where the TSC is still running.
34 In the TSC, go to the Site Monitor Page.
35 Verify the Own Site Monitor Address and Telegram Downlink Format is as verified with the site mon-
itor (DF= DF18, Mode S address as configured).
36 Verify the RX Level is set to approx. 10% below the one noted from that site monitor in step 30.
37 Verify the Repetition Interval is at least twice the configured interval.
38 If there is a second site monitor on site, repeat steps 35 to 37 with the parameters in the Other Site
Monitor group of the TSC Site Monitor page.
39 Verify correct setting of Test Target Report Trigger.
40 Verify correct setting of Tests Target Report Interval.
3.6.6 Configuration of Ground Station
1 Connect the LCMS serial cable to the Site Monitor maintenance port and the other side to the
USB−to−serial converter. Connect the USB−to−serial converter to the LCMS.
2 Start the LCMS and login as supervisor. Supply the appropriate password.
3 Connect Ethernet crossover cable to Ground Station auxiliary port located at the GTS module in
the upper left slot of the SPU. Connect the other side to the LCMS Ethernet port.
4 Start the Ground Station.
5 Verify that all failure LEDs are off after the Ground Station boot up sequence.
6 Start the TSC from the LCMS desktop.
7 Verify that the Ground Station parameters are properly retrieved by the TSC. The last log message
in the log message window should read All parameters retrieved!".
8 Go to the TSC BITE page.
9 Verify that all BITE results are "green" or disabled (grey).
10 Go to the Software Page.
11 Verify that the correct SW version and Kernel is installed.
12 Go to the Ground Station Page.
13 Verify that the Ground Station name, SAC and SIC is correctly configured.
14 Go to the Network Page.
15 Verify the correct configuration of parameters in group Main Network Configuration :
Ground Station IP−Address, Netmask, Default Gateway.
16 Verify the correct configuration of parameters in group Main Asterix Data Stream:
Output must be enabled, Host IP and Port .
