cutmaster a60
Manual 0-4981 3-3 INSTALLATION
E. Connections to Single Phase Input Power
WARNING
Disconnect input power from the power
supply and input cable before attempting
this procedure.
These instructions are for changing the input
power and or cable on the 208/230, 400, 460
VAC Power Supply to Single - Phase input
power.
1. Remove the Power Supply cover per in-
structions found in this subsection A.
2. Disconnect the original input power cable
from the main input contactor and the
chassis ground connection.
3. Loosen the through - hole protector on the
back panel of the power supply. Pull the
original power cable out of the power sup-
ply.
4. If the power cable being used is not the
factory - supplied cable, use a three - con-
ductor input power cable for the voltage
desired and strip back the insulation on the
individual wires.
5. Pass the cable being used through the
access opening in the back panel of the
power supply. Refer to Section 2 for
power cable specications.
CAUTION
The primary power source and power cable must
conform to local electrical code and the recom-
mended circuit protection and wiring require-
ments (refer to table in Section 2).
6. Connect the wires as follows.
Set Jumper wire and copper bus bar /
jumper on the contactor. See previous
illustrations.
Green / Yellow wire to Ground.
Remaining wires to L1 and L2 input. It
does not matter what order these wires
are attached.
7. With a little slack in the wires, tighten
the through - hole protector to secure the
power cable.
8. Reinstall the Power Supply cover see sub-
section B.
9. Connect the opposite end of individual
wires to a customer supplied plug or main
disconnect.
10. Connect the input power cable (or close
the main disconnect switch) to supply
power.
F. Connections to Three Phase Input Power
WARNING
Disconnect input power from the power sup-
ply and input cable before attempting this
procedure.
These instructions are for changing the input
power and or cable on the 208/230, 400, 460 VAC
Power Supply to Three - Phase input power.
1. Remove the Power Supply cover per in-
structions found in this subsection A.
2. Disconnect the original input power cable
from the main input contactor and the
chassis ground connection.
3. Loosen the through - hole protector on the
back panel of the power supply. Pull the
original power cable out of the power sup-
ply.
4. Using a customer supplied four - conductor
input power cable for the voltage desired,
strip back the insulation on the individual
wires.
5. Pass the cable being used through the
access opening in the back panel of the
power supply. Refer to Section 2 for
power cable specications.
CAUTION
The primary power source and power cable must
conform to local electrical code and the recom-
mended circuit protection and wiring require-
ments (refer to table in Section 2).
