A80
0-4985 OPERATION
4-3
STANDOFF
A80 Gas Pressure Settings
Leads
Length
SL100
(Hand Torch)
SL100
(Mechanized Torch)
SL 100 SV
(Automated Torch)
Up to 50'
(7.6 m)
75 psi
5.2 bar
75 psi
5.2 bar
Each
additional
25' (7.6 m)
Add 5 psi
0.4 bar
Add 5 psi
0.4 bar
3. For Drag cutting (60 Amps and below), adjust gas
pressure from 75 - 95 psi / 5.2 - 6.5 bar (LED's in
center of control panel). Refer to the Drag Cutting
chart for pressure setting details.
DRAG (60 amp or less)
A80 Gas Pressure Settings
Leads
Length
SL100
(Hand Torch)
Up to 25'
(7.6 m)
80 psi
5.5 bar
Each additional
25' (7.6 m)
Add 5 psi
0.4 bar
Select Current Output Level
1. Place the Function Control Knob in one of the
three operating positions available:
RUN ,
RAPID AUTO RESTART
or LATCH . Gas ow stops.
2. Set the output current to desired amperage with
the Output Current Control Knob.
Pre-ow
With hand or mechanical torch, there will be a .5 second
pre-ow of the gas. Pre-ow does not apply to automa-
tion torch use.
Cutting Operation
When the torch leaves the workpiece during cutting
operations with the Function Control Knob in the RUN
position, there is a brief delay in restarting the pilot
arc. With the knob in the RAPID AUTO RESTART posi-
tion, when the torch leaves the workpiece the pilot arc
restarts instantly, and the cutting arc restarts instantly
when the pilot arc contacts the workpiece. (Use the
'Rapid Auto Restart' position when cutting expanded
metal or gratings, or in gouging or trimming operations
when an uninterrupted restart is desired). And with the
knob in the LATCH position the main cutting arc will be
maintained after the torch switch is released.
Typical Cutting Speeds
Cutting speeds vary according to torch output amper-
age, the type of material being cut, and operator skill.
Refer to Section 4T.08 and following for greater details.
Output current setting or cutting speeds may be re-
duced to allow slower cutting when following a line, or
using a template or cutting guide while still producing
cuts of excellent quality.
Postow
Release the trigger to stop the cutting arc. Gas contin-
ues to ow for approximately 20 seconds. During post
- ow, if the user moves the trigger release to the rear
and presses the trigger, the pilot arc starts. The main
arc transfers to the workpiece if the torch tip is within
transfer distance to the workpiece.
Shutdown
Turn the ON / OFF switch to OFF (down).
All Power Supply indicators shut OFF. Unplug the
input power cord or disconnect input power. Power is
removed from the system.
