A80
0-4985 OEPRATION
4T-15
Material
Thickness
Gas Pressure (Air) Arc Voltage
Torch Working
Height
Travel Speed
Initial Piercing
Height
Pierce Delay
Kerf Width
@ Rec. Speed
(mm)
Bar
(torch lead
length)
Volts (mm) (mm/min) (mm) (sec) (mm)
1
5.9 (7.6m)
6.2 (15.2m)
115 4.8 7540 4.8 0 2.1
2 120 4.8 7015 4.0 0.10 1.9
3 118 4.8 4570 4.8 0.10 0.1
4 120 4.8 3650 4.8 0.20 1.9
5 121 4.8 2465 4.8 0.20 2.1
6 122 4.8 2145 4.8 0.30 2.0
8 123 4.8 1635 4.8 0.40 2.2
10 125 4.8 1180 4.8 0.60 2.4
12 130 4.8 795 4.8 0.75 2.4
15 134 4.8 530 Edge Start 2.4
20 138 4.8 325 Edge Start 2.2
25 149 4.8 165 Edge Start 2.7
BOLD TYPE indicates maximum piercing parameters. BOLD ITALIC indicates edge starts only.
