Thermal Dynamics CUTMASTER A80 - 02 Automation Torch Parts Selection; 03 Machine and Hand Torch Parts Selection

CUTMASTER A80, A120
OPERATION 4T-2 Manual 0-5119
4T.02 Automation Torch Parts
Selection
Check the torch for proper consumable parts. The
parts supplied in the torch may not be correct for
the operator’s chosen amperage level. The torch
parts must correspond with the type of opera-
tion.
Torch parts:
Shield Cup, Cutting Tip, Electrode and Starter
Cartridge
NOTE
Refer to Sections 4T.08 and following for
additional information on torch parts.
Change the torch parts for a different operation
as follows:
WARNING
Disconnect primary power at the source
before assembling or disassembling torch
parts, or torch and leads assemblies.
NOTE
The shield cup holds the tip and starter cartridge
in place. Position the torch with the shield cup
facing upward to keep these parts from falling
out when the cup is removed.
1. If attached, remove the ohmic clip then
unscrew and remove the shield cup as-
sembly from the torch head. Wipe it clean
or replace if damaged
2. Remove the Electrode by pulling it straight
out of the Torch Head.
Art # A-04173
Electrode
Start Cartridge
Tip
Ohmic Clip
(If Installed)
Torch Head
Shield Cup Body
Shield Cap
Deflector
Automation Torch Parts
3. Install the replacement Electrode by push-
ing it straight into the torch head until it
clicks.
4. Install the starter cartridge and desired tip
for the operation into the torch head.
5. Hand tighten the shield cup assembly until
it is seated on the torch head. If resistance
is felt when installing the cup, check the
threads before proceeding
6. If used, attach the ohmic clip to the shield
cup.
4T.03 Machine and Hand Torch
Parts Selection
Depending on the type of operation to be done
determines the torch parts to be used.
Type of operation:
Drag cutting, standoff cutting or gouging
Torch parts:
Shield Cup, Cutting Tip, Electrode and Starter
Cartridge
