Thermal Dynamics CUTMASTER A80 - Page 51

CUMASTER A80, A120
Manual 0-5119 4T-15 OPERATION
Aluminum
60A
Air Plasma / Air Shield
Deector
Standard Shield Cup
Maximum Life Shield Cup
Tip Starter Cartridge Electrode
9-8243
9-8218
9-8237
9-8210 9-8213 9-8232
Material
Thickness
Gas Pressure
(Air)
Arc
Voltage
Torch
Working
Height
Travel
Speed
Initial
Piercing
Height
Pierce
Delay
Kerf Width
@ Rec.
Speed
(GA)
(in) inch
PSI
(torch lead length)
Volts
(in)
(ipm) (in) (sec) (in)
16
0.064
85 (25')
90 (50')
123 0.25 440 0.25 0.00 0.08
14
0.079 126 0.25 300 0.25 0.10 0.09
11
0.120 128 0.25 250 0.25 0.10 0.09
3/16 0.188 132 0.25 170 0.25 0.20 0.09
1/4 0.250 132 0.25 85 0.25 0.30 0.09
3/8 0.375 141 0.25 45 0.25 0.50 0.10
1/2 0.500 148 0.25 30 0.25 0.80 0.09
5/8 0.625 145 0.19 18 Edge Start 0.08
3/4 0.750 147 0.19 12 Edge Start 0.10
Material
Thickness
Gas Pressure
(Air)
Arc
Voltage
Torch
Working
Height
Travel
Speed
Initial
Piercing
Height
Pierce
Delay
Kerf Width
@ Rec.
Speed
(mm)
Bar
(torch lead length)
Volts (mm) (mm/min) (mm) (sec) (mm)
1
5.9 (7.6m)
6.2 (15.2m)
118 6.4 17010 6.4 0.00
1.8
2 126 6.4 7680 6.4 0.10
2.3
3 128 6.4 6410 6.4 0.10
2.3
4 130 6.4 5230 6.4 0.20
2.3
5 132 6.4 4010 6.4 0.20
2.4
6 132 6.4 2640 6.4 0.30
2.4
8 137 6.4 1630 6.4 0.40
2.4
10 142 6.4 1085 6.4 0.60
2.4
12 146 6.4 845 6.4 0.70
2.3
15 146 4.8 540
Edge Start
2.1
20 148 4.8 260
Edge Start
2.5
BOLD TYPE indicates maximum piercing parameters. BOLD ITALIC indicates edge starts only.
