CUTMASTER A80, A120
OPERATION 4T-24 Manual 0-5119
Aluminum
120A
Air Plasma / Air Shield
Deector
Standard Shield Cup
Maximum Life Shield Cup
Tip Starter Cartridge Electrode
9-8243
9-8218
9-8237
9-8233
9-8213
9-8232
Material
Thickness
Gas Pressure
(Air)
Arc
Voltage
Torch
Working
Height
Travel
Speed
Initial
Piercing
Height
Pierce
Delay
Kerf Width
@ Rec.
Speed
(GA)
(in) inch
PSI
(torch lead length)
Volts
(in)
(ipm) (in) (sec) (in)
1/4 0.250
80 (25')
80 (50')
139 0.19 180 0.25
0.30
0.11
3/8 0.375
140 0.19 110 0.25
0.50
0.11
1/2 0.500
143 0.19 75 0.25
0.80
0.11
5/8 0.625
156 0.25 50 0.30
1.00
0.12
3/4 0.750
161 0.25 34 Edge Start 0.13
1 1.000
167 0.25 23 Edge Start 0.14
Material
Thickness
Gas Pressure
(Air)
Arc
Voltage
Torch
Working
Height
Travel
Speed
Initial
Piercing
Height
Pierce
Delay
Kerf Width
@ Rec.
Speed
(mm)
Bar
(torch lead length)
Volts (mm) (mm/min) (mm) (sec) (mm)
6
5.5 (7.6m)
5.5 (15.2m)
139
4.8
4770 6.4 0.2 2.8
8 140 4.8 3650 6.4 0.2 2.8
10 140
4.8
2660
6.4
0.5 2.8
12 142 4.8 2100 6.4 0.8 2.8
15 152
6.4
1445
7.6 1.2
3.0
20 162
6.4
820
Edge Start
3.4
25 167
6.4
600
Edge Start
3.4
BOLD TYPE indicates maximum piercing parameters. BOLD ITALIC indicates edge starts only.
CUTMASTER A120
ONLY
