ULTRA-CUT 200 XT

6-12 REPLACEMENT PARTS Manual 0-5304

6.13 TSC-3000 Touch Screen Control Remote and Internal Replacement Parts

Item # Qty Description Catalog #

1 1 Assy, TSC-3000, Remote, Demo 9-9490D

2 1 Touch Panel Computer 9-7543

3 1 Switch, Rocker SPST 9-1042

4 1 Ribbon Cable HMI to Interface PCB N/A

5 1 PCB 9-7547

6 1 USB Panel Mount Extension 9-7545

Art # A-09165_AC
