ULTRA-CUT 200 XT
Manual 0-5304 SPECIFICATIONS 2-5
2.09 Gas Requirements
The customer will provide all gases and pressure regulators. Gases must be of high quality. Pressure regulators shall be double
stage and installed within 3 meters from the Gas Console.
Ultra-Cut 200 XT™ Power Supply: Gas Pressures, Flows, and Quality Requirements
Gas Quality Minimum Pressure Flow
O
2
(Oxygen)
99.5% Purity
(Liquid recommended)
120 psi
8.3 bar / 827 kPa
200 scfh (95 lpm)
N
2
(Nitrogen)
99.5% Purity
(Liquid recommended) <1000
ppm O
2
, <32 ppm H
2
O)
120 psi
8.3 bar / 827 kPa
200 scfh (95 lpm)
Compressed
or Bottled Air
Clean, Dry,
Free of Oil (see Note 1)
120 psi
8.3 bar / 827 kPa
450 scfh (212.4 lpm)
H35 (Argon-Hydrogen)
H35 = 35% Hydrogen,
65% Argon
99.995% Purity
(gas recommended)
120 psi
8.3 bar / 827 kPa
200 scfh (95 lpm)
Ar (Argon) 99.995% Purity
(gas recommended)
120 psi
8.3 bar / 827 kPa
150 scfh (70.8 lpm)
H
2
O (Water) See Note 2 55 psi (3.8 bar) 10 gph (0.6 lpm)
Note 1: The air source must be adequately filtered to remove all oil or grease. Oil or grease
contamination from compressed or bottled air can cause fires in conjunction with oxygen.
For filtering, a coalescing filter able to filter to 0.01 microns should be placed as close as
possible to the gas inlets on the Gas Control Module.
Note 2: The tap water source does not need to be deionized, but in water systems with extremely high mineral content a
water softener is recommended. Tap water with high levels of particulate matter must be filtered.
Note 3: Water Pressure Regulator No. 8-6118 is recommended to ensure proper water pressure.
2.10 Gas Applications
MATERIAL MILD STEEL STAINLESS STEEL ALUMINUM
GAS TYPE GAS TYPE GAS TYPE
OPERATION PREFLOW PLASMA SHIELD PREFLOW PLASMA SHIELD PREFLOW PLASMA SHIELD
30A Cut
Air O
2
O
2
Air Air Air Air Air Air
N
2
N
2
H
2
0 N
2
N
2
H
2
0
50A Cut
Air O
2
Air Air Air Air Air Air Air
N
2
N
2
H
2
0 N
2
N
2
H
2
0
70A Cut
Air O
2
Air Air Air Air Air Air Air
N
2
N
2
H
2
0 N
2
N
2
H
2
0
100A Cut
Air O
2
Air N
2
H35 N
2
N
2
H35 N
2
N
2
N
2
H
2
0 N
2
N
2
H
2
0
150A Cut
Air O
2
Air N
2
H35 N
2
N
2
H35 N
2
N
2
N
2
H
2
0 N
2
N
2
H
2
0
200A Cut
Air O
2
Air N
2
H35 N
2
N
2
H35 N
2
N
2
N
2
H
2
0 N
2
N
2
H
2
0
Marking Air Ar Air/ O
2*
Air/ N
2*
Ar
Air/ N
2/
H
2
0
Air/ N
2 *
Ar
Air/ N
2/
H
2
0
*Note: Depends on process used.
