ULTRA-CUT 200 XT
Manual 0-5304 INSTALLATION 3-1
SECTION 3: INSTALLATION
3.01 Installation Requirements
Electric Supply
The electrical supply network, the gas and water supply system must meet local safety standards. This conformity shall be
checked by qualified personnel.
Ultra-Cut 200 XT™ Power Supply
Input Power Input Current Suggested Sizes (See Note)
Voltage Freq. 3-Ph 3-Ph Fuse (Amps) Wire (AWG) Wire (mm
2
)
(Volts) (Hz) (kVA) (Amps) 3-Ph 3-Ph 3-Ph
480 50/60 42 52 100 #8 10
NOTE!
* Suggested wire size based on United States NFPA 70 National Electrical Code 2011 edition
published by the National Fire Prevention Association. Listings are from table 400.5(A)(2) for
flexible cord of certain types rated for 75 deg C in ambient temperatures up to 30 deg C. Using
wires of lower temperature rating or different insulation type may require larger wire size. De
rate for higher ambient.
These are suggestions only. Always refer to your local and national codes that apply to your
region for final determination of correct wire type and size.
Gas Supply
The customer must supply all gases and pressure regulators. Gases must be of high quality. Pressure regulators must be double-
stage and installed as close as possible to the gas console. Contaminated gas can cause one or more of the following problems:
• Reducedcuttingspeed
• Poorcutquality
• Poorcuttingprecision
• Reducedconsumableslife.
• Oilorgreasecontaminationfromcompressedorbottledaircancauseresinconjunctionwithoxygen.
Cooling System Requirements
Coolant must be added to the system on installation. The amount required varies with torch leads length.
Victor Thermal Dynamics recommends the use of its coolants 7-3580 and 7-3581 (for low temperatures).
Coolant Capabilities
Cat. Number and Mixture Mixture Protects To
7-3580 ‘Extra-Cool™’ 25 / 75 10° F / -12° C
7-3581 ‘Ultra-Cool™’ 50 / 50 -27° F / -33° C
7-3582 ‘Extreme Cool™’ Concentrate* -76° F / -60° C
* For mixing with D-I Cool™ 7-3583
