1930 mm
1550 mm
+5°C
OK
30°C
300 mm
300 mm
300 mm
10 mm
600 mm
Athena Total EQ
Athena Total 300L Athena Compact
x4
13mm
16mm
Adjust the heat pump using the adjustable feet and a spirit level.
Installation Guide Athena
Thermia AB AWAT01IGCG0102
19
