Caution Be careful not to damage the electrical wiring attached to the display
when the front cover is removed!
1. Press against the front cover and turn the catch 90° degrees anti-clockwise to release the front
cover.
2. Tilt the front cover outward.
3. Lift the front cover upwards to remove it from the unit.
In order to access the connections, the indoor unit's front and the metal plate to the electrical cabinet
must be removed.
Remove knock-out holes to the left or right.
Installation Guide Athena
Thermia AB AWAT01IGCG0102
35
