Thermo King CSR Series User Manual

MP-3000 Controller
124
56 Compressor Temperature Too High
(Shutdown Alarm)
• Compressor discharge line temperature is above
148 C (298 F). Compressor stopped until discharge
line temperature decreases to normal.
• Indicates:
• Air in refrigeration system
• Low refrigerant charge
• Defective compressor or valve plate
• Defective liquid injection system
• Wrong or defective sensor
• Operate unit on Cool and check discharge and
suction pressure gauge readings.
• Enter Manual Function Test menu and test
(operate) Injection Valve to determine if valve
opens (energizes).
• Check compressor discharge sensor
resistance. Resistance must be 100,000 ohms
at 25 C (77 F).
• Check discharge line temperature with a
separate electronic thermometer and compare
to “HIGH PR TEMP” shown in the Data menu
of controller.
NOTE: Unit will operate normally without
compressor sensor. However, controller
compressor high temperature protection is
not active.
57 AFAM Control Module or Motor Error
(Check Alarm)
• Controller is unable to adjust vent door to desired
position.
• Indicates:
• Frozen or stuck vent door
• Defective linkage
• Defective control module
• Open circuit to control module or motor
• Defective motor
• Visually inspect the vent door and linkage for
ice or obstruction. Check for proper linkage
adjustment.
• Check wiring connections to the AFAM circuit
board for continuity using a high quality
multimeter.
• Check motor winding for continuity using a
high quality multimeter.
58 Phase Sensor Error
(Check Alarm)
• Occurs during pre-trip (PTI) or function test only.
• During Phase Sensor Test, amperage difference
between correct and wrong condenser fan rotation
is more than 0.2 amps.
• Indicates:
• Defective phase relay
• Defective relay board
• Defective relay board cable No. 2
• Start a Function Test. During step F1.05,
check whether the phase relays on relay
board receive a signal (LED energizes). Verify
that the relays respond and shift to reverse
phase.
59 Delta Current Error
(Check Alarm)
• 100% ampere difference between current phases.
• Indicates:
• Open connection on one phase of power supply
to a motor or heater element
• Enter Manual Function Test menu and test
(operate) each 3-phase component to locate
defective connection.
Alarm Codes, Descriptions and Corrective Actions (Continued)
