Unit Description
40
AXA0230
1
2
6
5
4
3
1. Compressor Discharge Temperature Sensor
2. Suction Service Valve (Option) with Service Fitting
3. Compressor Oil Sight Glass
4. Compressor Oil Fitting
5. Discharge Service Valve (Option) with Service Fitting
6. High Pressure Cutout Switch (Units After 7/00)
Figure 10: Scroll Compressor
