Unit Description
34
AXA0222
3
1
2
1. Evaporator Fan Blade (see “Physical Specifications” on page 26 for description)
2. Evaporator Fan Motor
3. Return Air Sensor
Figure 4: Evaporator Front View — CSR20SL & CSR40SL
