Thermo King CSR Series User Manual

Specifications
26
Physical Specifications
Fresh Air Exchange Venting System (Adjustable):
CSR20SL
0 to 160 m
3
/hr (0 to 96 ft
3
/min.) @ 60 Hz
0 to 134 m
3
/hr (0 to 79 ft
3
/min.) @ 50 Hz
CSR40SL and CSR40
0 to 280 m
3
/hr (0 to 165 ft
3
/min.) @ 60 Hz
0 to 232 m
3
/hr (0 to 136 ft
3
/min.) @ 50 Hz
Evaporator Fan Blade Specifications:
CSR20SL:
Diameter 270 mm (10.6 in.)
Pitch 25°
Number 3
CSR40SL:
Diameter 312 mm (12.25 in.)
Pitch 25°
Number 3
CSR40:
Diameter 355 mm (14.0 in.)
Pitch 25°
Number 2
Weight (net):
CSR20SL Base Unit 392Kg (865 lb.)
CSR40SL Base Unit 402 Kg (885 lb.)
CSR40 Base Unit 413 Kg (910 lb.)
Full TRANSFRESH
®
Option
13 Kg (28 lb.)
Water-cooled Condenser-Receiver Option 13.6 Kg (30 lb.)
Unit Dimensions:
A = Flange Width 2025.5 mm (79.74 in.)
B = Gasket Width 1935 mm (76.18 in.)
C = Unit Width 1894 mm (74.57 in.)
D = Flange Height 2235.2 mm (88.00 in.)
E = Gasket Height 2140 mm (84.25 in.)
F = Unit Height 2094 mm (82.44 in.)
G = Gasket Depth 72 mm (2.83 in.) from back of flange
H = Maximum Protrusion 37 mm (1.46 in.) from back of flange
I = Unit Depth: CSR20SL 335.0 mm (13.18 in.) from back of flange
CSR40SL 378.0 mm (14.88 in.) from back of flange
CSR40 420.0 mm (16.54 in.) from back of flange
J = CSR40 Evaporator Access Door
K = CSR20SL and CSR40SL Evaporator Access Door
L = Condenser Grille CSR Models Before 4/01
M = Condenser Grille CSR Models After 4/01
