Unit Description
38
AXA0228
654321
1. Sensing Bulb Option for recording Thermometer (Return Air)
2. Gas Sensor Unit for AFAM+ Option, see page 45
3. Vent Loop for Gas Sensor for AFAM+ Option
4. Filter for Gas Sensor for AFAM+ Option
5. Humidity Sensor for Dehumidify Option or Humidity Option
6. Air Compressor for Humidity System Option, see page 43
Figure 8: CSR40 & CSR40 Options — Evaporator Front View
